CLG HARDWARE Extra Heavy Duty Commercial Door Closer, DC9016 Automatic Door Closer, Surface-Mounted Auto Door Closer, Size 1-6 Commercial Door Closer Heavy Duty for Heavy Traffic Areas, Dark Bronze
11 sold in last 24 hours
- DOOR CLOSERS COMMERCIAL USAGE: The DC9016 Automatic Door Closer from CLG HARDWARE suits high-traffic entrances, such as aluminum storefronts, factories, schools, restaurants, and other public places. This is a door automatic closer for doors that weigh up to 150kg (330lbs max) and are (800-1500mm, 31-60 inch) wide. Also, it is a non-handed closer that will work on left- or right-handed doors exposed to extreme temperatures.
- MATERIAL: This door hydraulic closer is manufactured from US26D satin chrome-plated cast iron, wrought steel arm. It features a heat-treated piston and a powder-coated body to enhance corrosion resistance. The heavy-duty door closer features three valves for adjustable closing speed, latching speed, and backcheck. This automatic door closer latches while maintaining quiet operation.
- CERTIFICATIONS: These auto close door hinges have a UL-certified three-hour fire rating. CLG HARDWARE closers also carry the ANSI / BHMA A156.4 certification. As ANSI Grade 1 commercial door hardware with 2 million cycles required, DC9016 suits medium- to high-traffic applications, like in department stores, schools, and offices. This model also complies with accessible design standards.
- INSTALLATION: Every pack of commercial door closer contains all the necessary hardware, such as brackets and soffit plate, for installation using any of the 3 mounting types. The mounting options for our surface-mounted door closer are regular arm mounting, top jamb mounting, and parallel arm mounting. With the flexibility to choose the best fit for your door make this the ideal choice for businesses looking to upgrade their security. Say hello to a seamless and efficient installation process!
- SPECIFICATIONS: This door closer weighs 12.6 pounds. Its screw/bolt pattern is 5" c-c wide and 2-1/4" c-c high. It has a footprint height of 3-1/2" (89 mm) and a weight of 12-1/4" (311 mm). This automatic door closer's projection is 2-1/4" (57 mm). It can deliver a fixed spring force #1-6 of 2-14 pounds or more of closing force. Recommended for high abuse and heavy traffic doorways.
Tags |
Estimated shipping
Select a product to estimate shipping.| Main Specification | |
|---|---|
| Specificazione Met | UL or Ansi |
| Produttore | Clg Hardware |
| Exterior Finish | Bronze |
| UPC | 195893553181 |
| Product information | |
| Dimensioni del pacchetto | 13.58 X 4.72 X 3.98 Inches |
| Technical Details | |
| Color | Dark Bronze |
| Material | Cast Iron |
| Item Weight | 10 Pounds |
| Installation Type | Screw-In |
| Size | Extra Heavy Duty |
| Numero della parte | Clg-Clg9016-Bc-Da-Duro |
| Style | Grade 1 |
| Item Package Quantity | 1 |
| Caratteristiche speciali | Machine And Wood Screws |
| Batteries Required? | No |
| Batteries Included? | No |
| Brand | Clg Hardware |
| Item details | |
| Recommended Uses For Product | High-Traffic Areas or Heavy Doors or Commercial Or Public Settings |
| Included Components | Brackets And Soffit Plate To Allow Regular/Top Jamb/Parallel Arm Installations |
| Others | |
| Tipo di prodotto | Door Closer |
